MDC 4204 - 20.000 DWT Product Tanker

General Description

MDC 4204 is a Product and Chemical Tanker, with coated cargo tanks, designed for world wide operations.

Double bottom / sides are arranged throughout the cargo area and in way of all fuel tanks.

The new hullform includes a new developed wave-piercing bow shape giving excellent performance and reduced ship resistance, both in stillwater and in waves / heads seas, resulting in reduced service allowance.

The design can be from an easy low cost, basic diesel fuelled variant to a more advanced Gas / DF solution, ice strengthened options, and cargo tank arrangements adapted to operators requirements.

Meeting latest EEDI and emission standards.

Main Particulars
Length overall
Length betw perp
Breadth, mld.
Depth, main deck
Draught, design
Draught, scantling

abt. 170,00 m
160,20 m
24,50 m
13,10 m
9,30 m
abt. 9,65 m
Deadweight and cargo capacity
Deadweight, design
Deadweight, scantling
Cargo tanks

18.500 tonnes
20.000 tonnes
24.500 m3
Speed
Trial speed
Service speed

abt. 16 knots
abt. 14 knots
Cruising Range and fuel consumption
Cruising range in service condition
Fuel consumption at CSR, propulsion

11.500 nm
abt. 13,8 t/d
For more details, please contact MDC AS.
